DESCRIPTION

Overview

Basic Info.

Model NO.	QK-ZGX
Motor Power	0.18kw, 0.25kw, 0.37kw, 0.55kw 0.75kw 1.1kw
Peripheral Speed	1-2m/Min
Structure	Truss Type
Material	Stainless Steel 304,Carbon Steel
Product Name	Peripheral Drive Clarifier
Transport Package	Bulk or High Quality Wooden Box Packaged
Specification	12m~56m Pool Diameter
Trademark	Qiankun
Origin	China
HS Code	8421219909
Production Capacity	500PCS/Year

Product Description

Product DesctriptionHigh Energy-efficient drive Sludge Scraper Clarifier for Waste Water Treatment
Qiankun EP has more than 16 years of forging ahead, owning abundant practical experience and high-tech research team, launch a whole chain industrial enterprise, which offers a one-stop service for all kinds of waste water treatment project and has accumulated hundreds of references in pulp and paper, printing and dyeing, chemical fiber, chemicals, leather, breeding, etc. Various kinds of industries and municipal sewage treatment projects. Business scope covers: Three waste treatment; all kinds of industrial and domestic wastewater treatment project EPC, kitchen waste treatment, landfill leachate treatment, soil remediation and manufacturing of all kinds of environmental protection equipment.

Product Description

Peripheral Drive Clarifier in WWTPs

QK Peripheral drive Clarifier is installed on medium and large size circular setting tanks in wastewater treatment plants. Feed water passes through the center pillar from bottom to the top, then distribute evenly into tank. Outlet water overflow though weir around tank, which keeps a stable water quality and quantity.

Features

A. Truss bridge structure, more economical and weight light;

B. Lower operation cost, easy maintenance and management;

C. Advanced transmission device, simple installation;

D. Safe and reliable, over-torque protection for option, when torque reaches to a certain place, it will give alarms and stop working;

E. PLC control system for option and customized start/ stop time.

Structures and Principles

Peripheral drive Clarifier is composed of: a mobile truss beam, two end driving trolley, two rotations with peripheral driving system, scrapers, suckers, scum skimmers, flow guidance, sludge collectors, center pit, electric cables and control cabinet.

The sludge feed in from top middle pillar (deviated by the weir in order to optimize the thickening), sludge scraper blades remove the sludge accumulated on the bottom and collect it in a central pit wherefrom, by a pump, is conveyed to the outlet though a pipe. Outlet sludge can return or disposal to sludge thickening tank. Above scum is skimmed to collection bucket for further disposal.

Product Parameters

Peripheral Drive Clarifier Parameters

Type	Tank Diameter(m)	Tank depth(m)	Line speed(m/min)	Power(kW)
QK-ZGX12	12	3.5	1-2	0.18
QK-ZGX14	14	3.5	1-2	0.18
QK-ZGX16	16	3.5	1-2	0.25
QK-ZGX18	18	4.0	1-2	0.25
QK-ZGX20	20	4.0	1-2	0.37
QK-ZGX25	25	4.0	1-2	0.37
QK-ZGX30	30	4.5	1-2	0.55
QK-ZGX36	36	4.5	1-2	0.55
QK-ZGX42	42	4.5	1-2	0.75
QK-ZGX48	48	4.5	1-2	0.75
QK-ZGX56	56	4.5	1-2	1.10

Detailed Photos

Product package: To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Customer Visit

Company Profile

Qiankun is a high-tech enterprise integrating R&D, engineering, manufacturing, installation, marketing and after-sale service. In cooperation with Tsinghua University, Beijing University, Zhengzhou University and He' nan Normal University, we keep technical research and innovation. Our market has extended from the traditional wastewater treatment to the ecological fields. Following the 13th five-year environmental protection industry planning and market demand, we start to involved in the harmlessness and resourceful treatment of urban and rural domestic waste, industrial solid waste disposal, soil remediation and ecological restoration, development & utilization of clean energy and other environmental areas.As a result of our exquisite design, high quality products and outstanding customer service, we gained a global sales network reaching Iran, India, Egypt, Thailand, Malaysia, Vietnam, Ethiopia, Russia etc.Certifications

Our Certificate
Owns the certifications of qualification as general contractor of Environmental Engineering project, qualification as general contractor of municipal utilities construction, general contractor of urban landscaping project, and gains ISO9001 quality management system certificate, ISO14001 environmental management system certificate, and OHSAS18001 established occupational health and safety management system certificate.
Pantent Product
Submersible aeratorIdentified as one of the best mixing type aerator in China, QK-QB Submersible Aerator, introducing high-tech from Finland, is a new self-developed submersible type aerator. Patent NO. ZL200910064575.9.
Aerator mixer
QK-TB Aerator mixer, introducing high-tech from UAS, is a new self-developed plug-flow type aerator. Patent NO. ZL201410833871.1FAQ

FAQ:

Q: How can I know more about this product?

A: we got 7/24 technical service on line, please contact us through e-mail or phone freely.

Q: Have you some working videos?

A: Yes, we can provide.

Q: Can you customize products for us?

A: Yes, we can produce as your drawings or other requirement.

Q: How about after-sales service?

A: 1 year free warranty, Lifetime technical service support.

Q: How can I install?

A: we got install instruction and video, or we can send engineer for install guidance.

Q: How about payment?

A: 100%T/T, 30% advance payment, the rest paid before shipping.
